Ortofon MC Cadenza Black
Technical data | |
Output voltage at 1000 Hz, 5cm/sec. | 0,33 mV |
Channel balance at 1 kHz | < 0,8 dB |
Channel separation at 1 kHz | > 27 dB |
Channel separation at 15 kHz | > 20 dB |
Frequency range at – 3dB | 20 – 60.000 Hz |
Frequency response 20 kHz – 20 kHz | +1,5/0 |
Tracking ability at 315Hz at recommended tracking force *) | 90 µm |
Compliance, dynamic, lateral | 16 µm/mN |
Stylus type | Nude Shibata on Boron cantilever |
Stylus tip radius | r/R 6/50 µm |
Tracking force range | 2,0-2,5 g (20-25 mN) |
Tracking force, recommended | 2,3 g (23 mN) |
Tracking angle | 20° |
Internal impedance, DC resistance | 5 Ohm |
Recommended load impedance | > 10 Ohm |
Cartridge body material | Stainless steel Aluminium |
Cartridge colour | Black/Black |
Cartridge weight | 10,7 gram |
